> For the complete documentation index, see [llms.txt](https://support.rosysalonsoftware.com/llms.txt). Markdown versions of documentation pages are available by appending `.md` to page URLs; this page is available as [Markdown](https://support.rosysalonsoftware.com/rosypay/activating-your-wireless-cloud-terminal.md). # Activating your Wireless Cloud Terminal ## Below, you will find instructions on how to activate wireless terminals by connecting them to Wi-Fi All devices supported by RosyPay: * Wi-Fi * Ingenico iSMP4 * Ingenico Link/2500 * Move 5000 ## Ingenico iSMP4 ![Ingenico iSMP4](/files/0a8bd5117ac55b403086dcf4644dd014c842f788) {% stepper %} {% step %} ### Configure Wi-Fi 1. Boot up the device. 2. Press the F *(Function button)* 4 times RAPIDLY. 3. Select Access Points by pressing F4. 4. Select New by pressing F1 – Device will start scanning for Networks. 5. Device will list all available Wifi connections, press F1 or F3 to move up and down. 6. Once the correct Wifi is found, press the Green button. 7. Press Green button again. 8. Enter Wifi Password *(T9 text)*, then press the Green button again. {% endstep %} {% step %} ### Retrieve the activation code Once successfully connected, device will display an Activation Code. {% endstep %} {% step %} ### Activate the terminal Activate the terminal through MerchantTrack. {% endstep %} {% endstepper %} ## Ingenico Link/2500 To get started with your Link/2500 power the device on and allow it to boot up to the triPOS screen. Tap 0-0-0-1 ![Ingenico Link2500](/files/60590e5ce3f2c0fe8a4f8aa94235ed6fee03a2d6) You will use the F2/F3 key to scroll to WIFI Parameters: ![Ingenico Link2500 2](/files/4a865693b93449c5ed3cfb48073e355746451193) The second menu, you will select Scan Network. Once the list of Networks have populated use the F2/F3 key to scroll and highlight your network. When you have highlighted your network use the green button to select your network ![Ingenico Link2500 3](/files/585b51e62754f4c5916bb80f8bf14f63cd518455) You must now enter your WiFi password. This can be done using multi-tap entry with the pin pad buttons, much like you enter text on a flip-phone (T-9) or use the Function (F) keys at the top to scroll the On-Screen keyboard. ![Ingenico Link2500 4](/files/65fd80cb5d0fdc8e1477fbe8ec0d32ad0f2f2419) * (F1) - Scrolls the selection to the left * (F2) - Scrolls the selection up * (F3) - Scrolls the selection down * (F4) scrolls the Selection to the Right ![Ingenico Link2500 5](/files/3aabb3363a035ecd8e105ea62ffee8b4305af45b) Once the password is entered (Password is case sensitive) your device will show "New Profile OK" and will kick you back to the main screen where the wifi symbol should now be connected and green in the top left. Once green, an activation code should populate on the screen. If you do not get an activation code If plugged in: Press and hold the # and Yellow keys, the device will reboot. If unplugged: the device will power down, power the device back on by holding the green key. ![Ingenico Link2500 6](/files/45e18c8d247b67e3b2d429c0964bd49be1bf22b9) Tips The keypad uses multi-tap entry, for example, pressing the 2 button repeatedly will go through the number 2 and the letters a, b and c in both lower and upper case. To enter a symbol, press the symbol button (.,#\*). To erase something typed, press the yellow button. * When needing to go back a previous screen, press the red button. * The chip reader should turn on automatically when connected to a power source. * Power down the device by holding the symbol button (.,#\*) and the yellow button simultaneously. ## Ingenico Move 5000 To connect the terminal to WiFi, power the device on and allow it to boot to the FULLSTEAM screen, once on this screen tap 0-0-0-1 ![](/files/004f53a1c306c59c9b4bfe70da3266d226426a15) On the next screen you will select **WIFI Parameters** using the touch screen feature. ![](/files/ec5ef07f35a43c4b2ee5c06992b24947c7612d9d) Select **Scan Network**. Once the list of Networks populates, select the network you are trying to connect ![](/files/109719524610daf656567e102ac8e4bd48244510) You will then need to enter your password, this can be done T-9 texting style by repeatedly tapping the numbers for the appropriate letters or you can use the touch screen for the keyboard. Once the password is entered (Password is case sensitive) the device will show "New Profile OK" and will bring you back to the main screen where the wireless connection in the top left should turn green. ![](/files/7dddf0071f9fa862d4ef6f8a0350ad20427f4548) An activation code should populate on the screen. If not, press and hold the # and Yellow keys, the device will reboot (If plugged in, If unplugged the device will power down, power the device back on by holding the green key) ## Activating the Terminal through MerchantTrack {% stepper %} {% step %} ### Log in to MerchantTrack Log into MerchantTrack, using the single sign on by loging into your Rosy Salon Software Account (manage>advanced settings>credit card processing>merchanttrack). You **MUST** have an email address in your Employee Profile in order for this to work. (manage>basic settings>employees) {% endstep %} {% step %} ### Activate a terminal Click **Terminals** > **Activate Terminal**. {% endstep %} {% step %} ### Select a merchant Use the dropdown to select a merchant. This should already be pre-configured for you, but if you do not see a merchant, contact RosyPay for assistance. {% endstep %} {% step %} ### Select the terminal manufacturer Select your Terminal Manufacturer. 1. PAX will be used for PAX Aries 8 & PAX A920 Pro 2. Ingenico will be used for Link2500, ISMP4, Move5000, Lane3000, Lane7000 3. Verifone will be used for MX915 & MX925 {% endstep %} {% step %} ### Enter the activation code or serial number Enter the Activation Code or Serial Number as requested by the terminal type. The Activation Code will displayed on the terminal after successfully connecting to WiFi. {% endstep %} {% step %} ### Enter a terminal description Enter a brief description to help identify your terminal this will be the Name of the terminal displayed in Rosy Salon Software. {% endstep %} {% endstepper %} ![](/files/0560291c165e73b084976d3590b8a8a1c3fc1c5b) ![](https://support.rosysalonsoftware.com/hubfs/Knowledge%20Base%20Import/rtaImage-Aug-19-2022-12-40-39-25-PM) Once you have activated your terminal you will want to go back to Rosy Salon Software and refresh the Credit Card Processing page or go to manage>advanced settings>credit card processing here you will now see your activated cloud terminal and you are ready to start processing. ![](https://support.rosysalonsoftware.com/hubfs/Knowledge%20Base%20Import/rtaImage-Aug-19-2022-12-40-49-65-PM) ![Credit card processing settings](/files/7ef62661cdabf01e8e14388baa22c7bd3000f5cd) [**Checkout Using the Cloud Terminal**](/rosypay/checkout-using-the-cloud-terminal.md) --- # Agent Instructions This documentation is published with GitBook. GitBook is the documentation platform designed so that both humans and AI agents can read, navigate, and reason over technical content effectively. Learn more at gitbook.com. ## Querying This Documentation If you need additional information that is not directly available in this page, you can query the documentation dynamically by asking a question. Perform an HTTP GET request on the current page URL with the `ask` query parameter, and the optional `goal` query parameter: ``` GET https://support.rosysalonsoftware.com/rosypay/activating-your-wireless-cloud-terminal.md?ask=&goal= ``` `ask` is the immediate question: it should be specific, self-contained, and written in natural language. `goal` is optional and describes the broader end goal you are ultimately trying to accomplish on behalf of the user. GitBook uses it to tailor the answer towards what is most useful for that goal. The response will contain a direct answer to the question and relevant excerpts and sources from the documentation. Use this mechanism when the answer is not explicitly present in the current page, you need clarification or additional context, or you want to retrieve related documentation sections.
